Seminar Pricing

Seminar Pricing

Allow sufficient time to view the entire video judging by the times labeled on the particular seminar.You may pause it, start over or go back, but, when you leave the webpage you will not be able to retrieve it again.

0. Manual-J Heat Loss Seminar.....Free
    Includes:
       a. Why do you need a Manual J Heat Loss or Heat Gain
       b. How to fill out our forms
Free seminars
Why do a manual-J Heat Loss Heat Gain     Filling out our forms

The seminars listed with a price are now available. Others will be added as they become available

Worksheets - when needed can be printed. Seminars requiring worksheets will be marked with *'s. Worksheet PDF's will include worksheets for all seminars

1. *Components Seminar*.....$8.95
    Includes:

       a. Different type heat exchangers
       b. Differences-Air Seperators, Hydraulic seperators and installation
       c. Auto feeders, calculating water pressure
       d. Expansion tanks sizing, installation
       e. Circulators - Types, installation where & why's, sizing, pump curves
       f. Circuit setters
       g. Buffer tanks
       Approximate viewing time - 1 Hour 30 minutes

2. Boiler venting - natural draft, direct vent, power vent and Combustion air.....$6.95
    Includes

       a. Calculating combustion air
       b. Acquiring combustion air
       c. Venting definitions and variations
       d. Venting cast iron & high efficiency boilers
       e. Pictures showing how not to vent boilers
       Approximate viewing time - 1 Hour 17 Minutes

3. *Primary/secondary piping, high efficiency boilers*.....$8.95
    Includes:

       a. Which is primary & which is secondary
       b. Closely spaced teess
       c. Close spaced tee rules - spacing and rotation
       d. Converting from a manifold system to P/S
       e. Converting from a manifold system to P/S
       f. Mystery of what's happening between the close spaced tees
       g. Proper header design when using closely spaced tees
       h. Converting from a manifold system to P/S
       i. What happens when piped as a boiler primary pipe?
       j. Converting from a manifold system to P/S
       k. Adding an IWH - Priority or not, does primary flow ever change places?
       l. Test Questions (not available yet)
       Approximate viewing time - 1 hour 7 minutes

4. CI Boiler Piping, Condensate Protection and System Type Review.....$7.95
    Includes:

       a. Boiler manifold piping
       b. Circulator location
       c. Zone valve location
       d. Bypass piping - Boiler or system bypass?
       e. Thermic valve operation
       f. 3 & 4 way valves
       g. Test Questions (not available yet)
       Approximate viewing time - 1 Hour 14 minutes

5. *Pipe Sizing for boiler, manifolds, zones and IWH's*...$7.95
    Includes:

       a. Determining GPM flow and pipe size
       b. Pipe Sizing for boiler manifolds
       c. Pipe Sizing for Zone piping
       d. Pipe sizing for IWH
       e. Choosing the correct circulator
       f. Test Questions (not available yet)
       Approximate viewing time - 1 Hour 5 Minutes minutes

6. Understanding Outdoor Reset.....$5.95
    Includes:

       a. How it works
       b. Understanding terms
       c. Installing OD sensors and wiring
       d. Changing setpoints and affectw on water temperature
       e. Test Questions (not available yet)
       Approximate viewing time - 45 minutes

7. All about domestic hot water from boilers.....$$$
    Includes:
       a. Boiler tankless coils
       b. Indirect water heaters
       c. Combi boilers
       d. Domestic hot water recirc
       e. Test Questions (not available yet)
       Approximate viewing time - 20 to 30 minutes

8. Multiple boiler installation overview.....>$$$
    Includes:

       a. Piping Practices
       b. Venting
       c. Common boiler pipe sizing (should take #5 pipe sizing first)
       d. Test Questions (not available yet)
       Approximate viewing time - 20 to 30 minutes

9. How to do a boiler start-up.....$$$
    Includes:

       a. Checking safety's
       b. Checking gas pressure
       c. Combustion testing
       d. Test Questions (not available yet)
       Approximate viewing time - 20 to 30 minutes

10. Understanding boiler electrical.....$$$
    Includes:

       a. Boiler and standard electrical symbols
       b. Explanation of relays
       c. Sizing control transformers
       d. Reading ladder and pictorial diagrams
       e. Test Questions (not available yet)
       Approximate viewing time - 40 to 60 minutes

11. Basic gas pipe sizing.....$$$
    Includes:

       a. Boiler manifold piping
       b. System manifold pipe sizing
       c. Zone pipe sizing
       d. Test Questions (not available yet)
       Approximate viewing time - 20 to 30 minutes

12. Hydronic Basics.....$$$$$
Suggested for new tech's as it is an explaination of components and gereral overview
    Includes:
       a. Boiler construction and heat exchanger differences ie. dry & wet base, steel cast iron high eff
       b. Fuel information & combustion
       c. Gas Boiler components and uses
       d. Oil Boiler components and uses
       e. Heat Emitters
       f. System components and uses
       g. DHW - explaination of various ways of production
       h. DHW - Steam boiler and system components
       i. Basics of boiler venting
       Approximate viewing time - 1 Hour 0 minutes

Not avaiable yet, check back 7/5/2022

The seminars listed with a price are now available. Others will be added as they become available FormCIBoilerProtection.cfm
